AUGER FOR LOG SPLITTER 150mm diameter - with replaceable tip
Model: S150K2
The sale product is auger for wood (with replaceable tip locked by pin) with a 150mm diameter, which is the first choice cone for building professional log splitters for industrial use with engine power above 7kW, as well as ideal for tractors. Auger with 150mm diameter consists of the most popular auger 80mm and extension enlarging its diameter to 150mm. Log splitter built on the basis of this auger with the extension will be the best solution for the most demanding customers for splitting large blocks of wood with a diameter of more than 40cm. The two-stage angle auger can handle with even the most gnarled wood. The tip of the cone is inserted and additionally locked by solid pin, making it sticks to the solid and will not fall out if you change the rotation.
Presented product was developed based on many years of experience and made entirely in our company with high quality materials, using modern numerical machines and technology - which ensures trouble-free operation for many years.
What are the advantages of our product:
What are the advantages of our product:
- We offer the highest quality products with 24 months Guarantee!
- You are buying directly from EUROPEAN MANUFACTURER!
- Specialized design of cone, allows to smooth and rapid crashing into the wood.
- The tip of the cone is subjected to professional heat treatment which maximizes its durability and longevity!
- All parts are made in our company, by EUROPEAN employees under strict quality control - by buying our kit you support the our economy.
- Very good value for money.
- Thousands of satisfied customers WORLDWIDE!
TECHNICAL DATA
Auger with replaceable tip (dowels):
[S080K2]
- Grade of material: experimentally chosen chrome steel with high-strength
- PROPERLY HARDENED TIP - which guarantees its high durability and longevity
- Auger diameter: 80mm
- The length of the auger: 230mm
- The length of the working part: 175mm
- The diameter of the hole for the shaft: ACCORDING TO TABLE BELOW
- Mounting the auger on shaft: ACCORDING TO TABLE BELOW
- A deep left-hand thread of the auger with a sharp shape ensures easy screwdriving in wood
- The tip is blocked by pin with 12mm diameter!, making the connection very strong
- Recommended auger speed: 400-600 rev/min
Choose the right size for fastening the auger for the shaft
Sizes marked with "phone" are available on request!
COMPONENTS OF THE AUGER:
The auger body (1):
[K-S080K2]
- The length of the body: 140mm
- The length of the working part of the body: 85mm
- Mounting exchangeable tip: spring pin 12mm!!
Exchangeable tip:
[SWK2]
- Grade of material: experimentally chosen chrome steel with high-strength
- PROPERLY HARDENED TIP - which guarantees its high durability and longevity
- The length of the tip: 115mm
- The length of the working part of the tip: 90mm
- Mounting in body: spring pin 12mm!!
- Tips are available in the continuous sale
Extension 150 for 80 auger:
[NS080-150]
- Grade of material: experimentally chosen chrome steel with high-strength
- Suitable for auger: fi 80mm
- The diameter of the extension: 150mm
- The length of the overlay: 80mm
- A deep left-hand thread with a sharp shape ensures easy screwdriving in wood
- The extension is locked with auger with two fixing screws, which ensures correct operation in both directions
FREQUENTLY ASKED QUESTIONS
Brand
Symbol
S150K2
Warranty
Warranty 24 months
Ask a question
Not confirmed by purchase
Score: /5
Write your opinion
Size | Shaft mount | Shaft bore diameter |
---|---|---|
W28A | 2 screws 12mm | 28mm |
W30A | 2 screws 12mm | 30mm |
W32A | 2 screw 12mm | 32mm |
W35A | 2 screw 12mm | 35mm |
W38A | 2 screw 16mm | 38mm |
W40B | 2 screw 16mm | 40mm |
W42B | 2 screw 16mm | 42mm |
W45B | 2 screw 16mm | 45mm |
